Microscopic

Interpenetrating Irregular Spherulitic Radial Ooids - Carboniferous (O/23/Carb/Aust)

10x
10x
2.5x
5x
5x
10x wave plate
2.5 cross nicols
5x cross nicol
5x cross nicol
10x wave plate
10x wave plate
2.5 wave plate
5x wave plate
5x wave plate
Outstanding feature Spherulitic radial calcite ooids, quartz, volcanic rock fragments(?), & equant spar
Folk Classification Oosparite
Dunham Classification Oolitic Grainstone
Common Grains Ooids,quartz& volcanic particles
Sorting Good
Rounding Good
Micritization & envelopes Most grains have thin micrite envelopes
Cement & diagenetic fabric Equant spar
Porosity Dense
Depositional Setting Highly saline high energy shoal water
Diagenetic history Cementation by freshwater calcite followed by interpenetration of grains

The sparse equant spar cements are probably freshwater cements dissolved from original aragonite and calcite. The radial calcite ooids accumulated on high energy shoals. Note ooid nucleae of quartz and volcanic material. Darkened grain rims are infestation of cyanobacteria colonies that cause local micritization. The sperulitic character of the ooids is interpreted to suggest that they formed and accumulated in a more restricted, probably highly saline, setting. However the skeletal grains are probably transported into this more restriced setting. The interpenetration of the ooids is interpreted to suggest that this section has potentially seen burial at sufficient depth to cause this effect; maybe the sediment was buried to 10,000 ft or more???
